2.5 MCC Eco NG Coolview
MCC Coolview is designed to assist in monitoring, diagnosing and troubleshooting of the vehicle HVAC
system via a communication cable between the controller and laptop/remote computer.
Communication
Section
Input Section
Switch Input Section
Output Section
Section Tabs
Figure 2-8 MCC Eco NG Coolview (Example Screen shot)
