Table 4-2 Pressure Transducer Voltage
“/hg Voltage Psig Voltage Psig Voltage Psig Voltage Psig Voltage Psig Voltage
20” 0.369 40 0.858 95 1.397 150 1.936 205 2.475 260 3.014
10” 0.417 45 0.907 100 1.446 155 1.985 210 2.524 265 3.063
Psig Voltage 50 0.956 105 1.495 160 2.034 215 2.573 270 3.112
0 0.466 55 1.007 110 1.544 165 2.083 220 2.622 275 3.161
5 0.515 60 1.054 115 1.593 170 2.132 225 2.671 280 3.210
10 0.564 65 1.103 120 1.642 175 2.181 230 2.720 285 3.259
15 0.614 70 1.152 125 1.691 180 2.230 235 2.769 290 3.308
20 0.663 75 1.204 130 1.740 185 2.279 240 2.818 295 3.357
25 0.712 80 1.250 135 1.789 190 2.328 245 2.867 300 2.406
30 0.761 85 1.299 140 1.838 195 2.377 250 2.916 305 3.455
35 0.810 90 1.348 145 1.887 200 2.426 255 2.965 310 3.504
