SECTION 5
ELECTRICAL
5.1 INTRODUCTION
This section includes electrical wiring schematics. The
schematics shown in this section provides information for the
Eco Xcel model rooftop air conditioning units which are fitted
with two evaporator blower/motor assemblies in each
evaporator section, and four (4) condenser fan motor
assemblies.
Additional technical data regarding wiring, electrical
connectors and relay assignment are listed below .
UNIT
CONTROLLER FIGURE NUMBERS
50-2104 MCC Figure 5-1
T50-2112 MCC Figure 5-2
