SECTION 1
DESCRIPTION
1.1 INTRODUCTION
This manual contains Operating Instructions,
Service Instructions and Electrical Data for the
EcoXcel Model Air Conditioning and Heating
equipment furnished by Mobile Climate Control as
showninTable1-1.
The system is identified with a Model/Serial number
tag located inside the evaporator section, on the rear
bulkhead wall of the assembly. Example is shown in
Figure 1-1.
Models consists of a Rooftop unit containing the
condensing section, the evaporator sections and
engine compartment mounted co mp ressor. To
complete the system, the air conditioning and
heating eq u ipmen t interfaces, electrical cabling,
refrigerant piping, engine coolant piping (for
heating), duct work and other components
furnished by Mobile Climate Control and/or the bus
manufacturer.
Additional support manuals are shown in Table 1-2.
Operation of the unit is controlled automatically by a
Mobile Climate Control Microprocessor based
controller. The controls maintain the vehicle's
interior temperature at the desired set point.
Table 1-1 Models
Model
Voltage Controller With Heat Single Loop W/Covers
50-2104 24 VDC
MCC EcoTemp NG
Microprocessor
Yes X X
T50-2112 24 VDC
MCC EcoTemp NG
Microprocessor
Yes X X
Table 1-2 Additional Support Manuals
MANUAL NUMBER
EQUIPMENT COVERED TYPE OF MANUAL
T-367PL Eco Xcel Models Service Replacement Parts List
