McCulloch Li 40T User Manual

12
- English
MAINTENANCE
General maintenance
!
WARNING! When servicing, use only
identical replacement parts. Use of any
other parts may create a hazard or cause
product damage.
!
WARNING! To avoid serious personal
injury, always remove the battery
pack from the tool when cleaning or
performing any maintenance.
Before each use, inspect the entire product for
damaged, missing, or loose parts such as screws,
nuts, bolts, caps, etc. Securely tighten all fasteners and
caps and do not operate this product until all missing or
damaged parts are replaced.
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types
of commercial solvents and may be damaged by their
use. Use clean cloths to remove dirt, dust, oil, grease,
etc..
!
WARNING! Do not at any time let
brake uids, gasoline, petroleum-based
products, penetrating oils, etc., come in
contact with plastic parts. Chemicals can
damage, weaken or destroy plastic which
may result in serious personal injury.
Only the parts shown on the parts list are intended to
be repaired or replaced by the customer. All other parts
should be replaced at an Authorised Service Centre.
Spool replacement
Use original manufacturer’s replacement cutting line for
best performance.
• Remove the battery pack.
• Push in tabs on sides of spool cover.
Tab
• Pull spool cover up to remove.
• Remove the old spool.
Cover
Spool
• To install the new spool, make sure the cutting line
is captured in the slot on the new spool. Make sure
the end of the cutting line is extended approximately
15cm beyond the slot.

McCulloch Li 40T Specifications

General

Power source	Battery
Battery voltage	40 V
Battery capacity	2 Ah
Battery charger included	Yes
Cutting width	350 mm
Product color	Black, Yellow
Rotational speed	5500 RPM
Cutting diameter (max)	- mm

Weight and Dimensions

Depth	180 mm
Width	120 mm
Length	1680 mm
Weight	5780 g
Package depth	970 mm
Package width	265 mm
Package height	165 mm
Package weight	5540 g
