ASSEMBLY
Attaching the front handle
• Loosen the two screws (a) in the handle with a
philips screwdriver (not included) and remove the
screws from the handle.
• Attach the front handle (b) and lower clamp (c) on
the shaft.
a
b
c
• Adjust handle up or down, if necessary, to desired
operating position.
• Tighten the two screws so that the handle cannot
be rotated on the shaft. The torque is 1.0-1.6 Nm.
