McHale W2020 - Front View of the Wrapper

McHale W2020 Round Bale Wrapper
8
2.2 Front view
No. Machine function
1 Lift arm (ribbed)
2 Bobbins
3 Dispenser trip arm
4 Dispenser motor and brake unit
5 Satellite dispenser arms (folded)
6 Top link
7 Dispenser
8 Hydraulic control valve (under panel)
9 Cut & hold
10 Side-tip (optional)
11 Lift arm (plain)
3
2
1
9
8
11 10
7
6
5
4
