McHale W2020 Round Bale Wrapper
9
2.3 General specifications
Units are given in both metric and UK imperial values, with the latter shown in brackets.
2.4 Tractor requirements
2.5 Optional equipment *
(*) May not be available in all countries, check with your McHale dealer for availability
in your country.
Side-tip option
The side-tip option is used for knocking the bale onto its side and is very useful for
coarse ground with strong stubble (which may have a tendency to puncture the film),
as it allows the bale to land on its edge, which has a much higher degree of film
coverage. It is also very useful on hilly/sloping ground as it can prevent bales from
rolling, when they land on their side.
Transport width 1.43 m (56”)
Transport length 2.47 m (97”)
Transport weight (unladen) 845 kg (1,863 lbs)
Maximum bale weight 1,200 kg (2,646 lbs)
Attachment Front/rear mounting
Electrics 12 V, 10 A socket approx (min. specification)
Hydraulic systems Open-Centre, Closed-Centre, Load-Sensing
Minimum hydraulic pressure 170 bar (2,465 psi)
Minimum hydraulic flow rate 20 l/min @ 170 bar (2,465 psi)
Spare film roll holders 2 x film roll holders, accommodating 4 rolls
Side-tip Retracting side-tip
Reverse valve Allows dispenser arms to reverse
Radio remote Allows remote control of the machine
Wired remote Remote hand piece
64% gears Alternative to standard 70% film stretch
