MIL (Yellow) - Malfunction Indicator Tell
tale Lamp. Tell-tale indicates a failure of an
emission system component.
Blank
Water in Fuel (Yellow) - Tell-tale indicates
water in the fuel filter.
Park Brake Applied (Red)
Trailer Park (Red) - Tell-tale is disabled.
ABS (Yellow) - Tell-tale indicates anti-lock
braking system malfunction.
Electronic Stability Control / Automatic
Traction Control (Yellow) - Tell-tale
indicates an Electronic Stability Control
(ESC) or an Automatic Traction Control
(ATC) event.
Brake Lights (Green) - Tell-tale illuminates
throughout the service brake application.
Engine Brake (Yellow) - Tell-tale indicates
the engine brake is activated.
Check Transmission (Yellow) - Move the
coach to a safe location and turn OFF
ignition. DO NOT change gear.
Stop Transmission (Red) - Tell-tale is
disabled.
Retarder Temperature (Red) - Tell-tale
illuminates when retarder oil temperature is
above 168 degrees Celsius for more than
ten (10) seconds.
Brake Wear (Yellow) - Tell-tale is disabled.
Fuel Filter Restriction (Yellow) -
Indicates the fuel filter has been clogged.
Tag Lock Fault (Red) - Tell-tale illuminates
when coach speed reaches 15 mph and
the tag cylinder does not lock.
Tell tale is OFF when coach speed returns
to 10 mph.
No Hill Start (Yellow) - Tell-tale is
disabled.
