Figure 84. REI ECD-5500 Dual Zone Controls
POWER: Turns the Radio ON / OFF.
SELECT KNOB: Used for setup viewing and selection of iPod control.
LEFT CONTROL Section: Includes SCAN, SEEK, BAND and iPod controls.
DISPLAY: Shows radio status.
RIGHT CONTROL Section: Includes CALL, END, DISP ( display ), Bluetooth controls
and MODE.
EJECT: Ejects the CD from the radio, if present.
MODE: Cycles between TUNER, WB ( Weatherband ), CD, USB / iPOD, BT Phone
( Bluetooth Phone ), BT Audio ( Bluetooth Audio ), AUX1 and AUX2 modes on the radio.
PRE_SETS and Playback Options: Allows user defined station pre-sets 1 through 6 and
playback options such as RPT ( Repeat ), RDM ( Random ), INT ( Intro ), FLDR Dwn
( Folder Down ), FLDR Up ( Folder Up ) and Play / Pause.
