15
Setup, con’t
19. Repeat steps 15 thru 18 until the new name of
“RENAME: BAL 1, MEDIA BRDG” is indicated
on the Front Panel Display. Refer to figures 13 thru
20.
20. To save the new name, press and hold in the IN-
PUT Control until “SETUP: MEDIA BRDG , ON
/ Name (Hold INPUT)” appears on the Front Panel
Information Display. Refer to figure 21.
4. Rotate the VOLUME (ADJUST) Control to change
from the “Switched” setting to “Unswitched”.
Refer to figure 23.
5. In a similar manner, perform steps 3 and 4 to
change the OUTPUT 2 setting. Refer to figures 24
and 25.
The C2700 Default Setting for using Headphones is to
automatically mute all the Output Connectors when
the Headphone Cable Plug is inserted into the C2700
Front Panel HEADPHONES Jack. There are two
available settings:
Mute All Outputs
Mute No Outputs
6. Rotate the INPUT Control until “SETUP: HEAD-
PHONES, Mute All Outputs ” appears on the
Information Display. Refer to figure 26.
7. Rotate the VOLUME (ADJUST) Control to change
the current HEADPHONES setting from “SETUP:
HEADPHONES, Mute No Outputs”. Refer to
f igures 27.
Figure 15
RENAME: BAL 1
>MEDIA <
Figure 14
RENAME: BAL 1
>MEDI <
The Output Settings provide the ability to change how
the C2700 Output 1, Output 2 and Headphones func-
tion.
OUTPUT 1 and 2:
By defaut OUTPUT 1 and 2 are set to go On/Off by
using the Front Panel OUTPUT 1 and 2 Push-buttons
or by using the OUTPUT 1 and 2 Push-buttons on the
Remote Control. If it is desirable to have OUTPUT 1
and/or 2 always On regardless of the OUTPUT 1 and
2 Push-button settings, perform the following:
1. Press and hold in the INPUT Control to enter the
SETUP MODE. Refer to figure 2 on page 13.
2. Rotate the INPUT Control until “SETUP: Out-
puts, (Hold INPUT)” appears on the Information
Display. Refer to figure 21.
3. Press and hold in the INPUT Control until
“SETUP: OUTPUT 1, Switched” appears on the
Display. Refer to figure 22.
Figure 16
RENAME: BAL 1
>MEDIA <
Figure 17
RENAME: BAL 1
>MEDIA B <
Figure 18
RENAME: BAL 1
>MEDIA BR <
Figure 19
RENAME: BAL 1
>MEDIA BRD <
Figure 20
RENAME: BAL 1
>MEDIA BRDG <
Output Settings
Figure 21
(Hold INPUT)
Figure 23
SETUP: OUTPUT 1
Unswitched
Figure 22
SETUP: OUTPUT 1
Switched
Figure 25
Unswitched
Figure 24
Switched
Figure 26
Mute All Outputs
21. Exit the SETUP Mode by several presses of the
INPUT Control.
Note: For convenience, an “Input Assignment Chart”
on a separate sheet “Mc5A/5B” has been pro-
vided to keep track of changes.
SETUP: MEDIA BRDG
On/Name (Hold INPUT)
Figure 21
