McIntosh C2700 User Manual

29
The Sampling Rate and the Bit Rate are determined
by the original recording, the Application Output
Format (when available) and the McIntosh-HD Control
Panel Settings.
Note: In general, when the original music is recorded
at a higher Sampling Rate, the result is usually
more detail in the music. However, this higher
rate results in consuming larger amounts of stor-
age space. The Sample Rate usually should be set
to match the Sample Rate of the music recording
being played back.
There are many third party Applications (besides
Applications like Windows Media Player) for stream-
ing music from the computer to McIntosh C2700 USB
Input. An example of just one of the available applica-
tions is “JRiver Media Center”.
Reset of Microprocessors
In the unlikely event the controls of the C2700 stop
functioning, the microprocessors can be reset by per-
forming the following:
1. Press and hold in the STANDBY/ON Push-button
until the LED above the STANDBY/ON Push-
button illumination is extinguished. Then release
the STANDBY/ON Push-button.
2. To switch the C2700 back On, press the STAND-
BY/ON Push-button.
Note: This can be performed with the C2700 On or in
the Standby Mode.
How to Operate the C2700, con’t
Figure 107
USB
46%
DSD128
Figure 108
USB
51%
DSD256

McIntosh C2700 Specifications

General

Preamplifier Type	Vacuum Tube
Number of Channels	2
Total Harmonic Distortion	0.08%
Signal to Noise Ratio	100dB
Outputs	3 (2 Balanced + 1 Unbalanced)
High Level Inputs	6
Frequency Response	20Hz to 20kHz +0, -0.5dB
Digital Audio Inputs	2 Optical, 2 Coaxial
Vacuum Tubes	6 12AX7A, 2 12AT7
Dimensions	17-1/2" (44.45cm) width x 7-5/8" (19.4cm) height x 18" (45.7cm) depth
Rated Output Voltage	2.5V Unbalanced, 5V Balanced
Maximum Output Voltage	16V Balanced, 8V Unbalanced
Phono Inputs	1 MC, 1 MM
Output Impedance	100 ohms Unbalanced, 200 ohms Balanced
Headphone Output	Yes
Type	Preamplifier
Gain	15dB (High Level), 40dB (MM), 60dB (MC)
