Your decision to own this McIntosh C2700 Tube Pre-
amplifier ranks you at the very top among discrimi-
nating music listeners. You now have “The Best.” The
McIntosh dedication to “Quality,” is assurance that
you will receive many years of musical enjoyment
from this unit.
Please take a short time to read the information in
this manual. We want you to be as familiar as pos-
sible with all the features and functions of your new
McIntosh.
Copyright 2019 © by McIntosh Laboratory, Inc.
Table of Contents
Thank You
Please Take A Moment
Technical Assistance
If at any time you have questions about your McIntosh
product, contact your McIntosh Dealer who is familiar
with your McIntosh equipment and any other brands
that may be part of your system. If you or your Dealer
wish additional help concerning a suspected problem,
you can receive technical assistance for all McIntosh
products at:
McIntosh Laboratory, Inc.
2 Chambers Street
Binghamton, New York 13903
Phone: 607-723-3512
Fax: 607-724-0549
Customer Service
If it is determined that your McIntosh product is in
need of repair, you can return it to your Dealer. You
can also return it to the McIntosh Laboratory Service
Department. For assistance on factory repair return
procedure, contact the McIntosh Service Department
at:
McIntosh Laboratory, Inc.
2 Chambers Street
Binghamton, New York 13903
Phone: 607-723-3515
Fax: 607-723-1917
The serial number, purchase date and McIntosh Dealer
name are important to you for possible insurance
claim or future service. The spaces below have been
provided for you to record that information:
Serial Number: _______________________________
Purchase Date: _______________________________
Dealer Name: ________________________________
Safety Instructions .............................................................. 2
(Separate Sheet)..........................Important Additional
............................................Operation Information Guide
Thank You and Please Take a Moment .............................. 2
Technical Assistance and Customer Service ...................... 2
Table of Contents ................................................................ 2
General Information ........................................................... 3
Trademark and License Information .................................. 3
Connector and Cable Information ...................................... 3
Introduction ........................................................................ 4
Performance Features ......................................................... 4
Dimensions ......................................................................... 5
Installation .......................................................................... 6
Connections:
Rear Panel Connections, Connecting Components .........7-8
Rear Panel Connections (Separate Sheet) ...................Mc2B
Connecting Components (Separate Sheets) ...............Mc1A,
......................................................................... Mc1B, Mc2A
Input Assignment Chart (Separate Sheet) ................. Mc5A,
......................................................................................Mc5B
Vacuum Tube Power:
Switching Power On to the C2700 Preamplifier ................. 9
Important Safety Information is supplied in a separate document “Important Additional Operation Information Guide”
Remote Control:
HR085 Remote Control Push-buttons ............................... 10
How to use the HR085 Remote Control ............................ 11
Front Panel:
Front Panel Displays, Controls, Push-buttons
and Jack .............................................................................. 12
Setup:
How to Operate the Setup Mode ....................................... 13
Default Settings ................................................................. 13
Fir mware Version .............................................................. 13
Input Settings ..................................................................... 13
Rename Input ..................................................................... 14
Output Settings .................................................................. 15
Power Control Triggers 1, 2, 3 and 4 ................................. 16
Data Ports, Passthru, HDMI (ARC) and (CEC) ................ 17
Lip Sync Mode (ARC) and Digital Gain ........................... 18
Comm Port Baud Rate ....................................................... 19
Remote Control Codes, IR Sensor .................................... 19
Power Mode, Factory Reset .............................................. 20
Operation:
How to Operate the C2700 ................................................22
Trim, Bass and Treble Tone, Mode and Meter Lights .. 22-24
Tube Lights, Display Illumination, Phono Ajustments,
HXD Mode ........................................................................25
Mute, Tone Controls, Output 1&2, Trim, Output Meter
Passthru, Headphone Jack .................................................26
How to make a Recording, Optical and Coaxial Inputs
USB Input Operation and Driver Installation
and Installing the Software ............................................... 27
USB Connection, Windows Sound Setting
Control Panel Settings, USB Music Playback ................... 28
Reset of Microprocessors ..................................................29
Additional Information:
Specifications..................................................................... 30
Packing Instruction ............................................................ 31
