27
How to Operate the MA5200, con’t
performing the following:
1. Press the STANDBY/ON Push-button until the
STANDBY/ON Indicator switches Off.
2. When the MA5200 cycles On then Off, release the
STANDBY/ON Push-button.
3. When the STANDBY/ON LED is illuminated
press the STANDBY/ON Push-button, the
MA5200 will resume normal operation.
Note: This can be performed with the MA5200 On or
in the Standby Mode.
Resetting the MA5200 to default settings
If it becomes desirable to reset all the adjustable set-
WLQJV6HWXSDQG7ULP6HWWLQJVWRWKHIDFWRU\GHIDXOW
values, perform the following:
1. Press in and hold the INPUT/TRIM Control and
the VOLUME/ADJUST Control. The Front Panel
Display will indicate “FACTORY RESET”. Refer
to figure 76.
2. When the Front Panel Display indicates “FAC-
TORY RESET, COMPLETE” release the two
controls. Refer to figure 77.
3. Press the STANDBY/ON Push-button and the
MA5200 will resume operation.
Figure 77
FACTORY RESET
-COMPLETE-
Figure 76
FACTORY RESET

Other manuals for McIntosh MA5200

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the McIntosh MA5200 and is the answer not in the manual?

McIntosh MA5200 Specifications

General IconGeneral
Power Output per Channel100 Watts
Number of Channels2
Total Harmonic Distortion0.005%
Input Impedance20k ohms
Rated Power Band20Hz to 20kHz
Dynamic Headroom1.8dB
Preamplifier OutputYes
Dual Mono Power SupplyNo
USB Input1
Coaxial Input1
Optical Input1
Damping Factor>200
Power Requirement120V 50/60Hz
Digital InputsCoaxial, Optical, USB
Frequency Response+0, -0.5dB from 20Hz to 20kHz +0, -3dB from 10Hz to 100kHz
