Dimensions

The following dimensions can assist in determining

the best location for your MA5200. There is additional

information on the next page pertaining to installing

the MA5200 into cabinets.

Rear View of the MA5200

Side View of the MA5200

Front View of the MA5200

17-

1/2"

44.5cm

5-3/8"

13.7cm

1-1/6"

2.7cm

29/32

1.8cm

15.2cm

16-1/16"

40.8cm

4-5/8"

11.8cm

13-1/4"

33.7cm

18-3/4"

47.6cm

16-1/2"

41.9cm

4-13/16"

12.2cm

3/16

0.5cm

2.5cm

13"

33cm

1-5/8"

4.1cm
