McQuay M5CKY28ER User Manual

M5LCY-II_(i) Application Information
13
Cable Size
Model Unit
M5CKY 28ER
M5CMY 28ER
M5CCY 28CR
M5CKY 40/50ER
M5CMY 40/50ER
M5CMY 62CR
M5CCY 38/50/60CR
M5CKY 40/50ER
M5CMY 40/50ER
M5CMY 62CR
M5CCY 38/50/60CR
(3 phase)
Power supply cable size mm
2
2.5 6 4
Number of wire 3 3 5
Interconnection cable size mm
2
1.5 1.5 1.5
Number of wire 4 4 4
Recommended fuse A 25 32 20
Refrigerant Piping
Model
Indoor
M5CKY 28ER
M5CMY 28ER
M5CCY 28CR
M5CKY 40/50ER
M5CMY 40/50ER
M5CMY 62CR
M5CCY 38/50/60CR
Outdoor M5LCY 28CR M5LCY 40/50/60FR
Max. Length, m 50 75
Min. Length, m 3 3
Max. Elevation, m 30 30
Liquid, mm / in 9.52 / 3/8”
Suction, mm / in 15.88 / 5/8”
Additional Charge
Indoor
M5CKY 28ER
M5CMY 28ER
M5CKY 40/50ER
M5CMY 40/50ER
M5CMY 62CR
M5CCY 38/50/60CR
Outdoor M5LCY 28CR M5LCY 40/50/60FR
Add Charge, g/m 50 50
For piping length above, m 7.6 30
Note: Installation and maintenance are to be performed only by qualifi ed personnel who are familiar
with local codes and regulations, and experienced with this type of equipment
