M5LCY-II_(i) Application Information
9
Installation Guideline
Sharp edges and coil surfaces are potential injury hazard. Avoid from contact with them.
Caution
Installation diagram
M5CKY 28/40/50ER
Indoor Unit
Outdoor Unit
Drain Piping
Front Panel
Air Filter
(behind the grille)
Air Intake Grille
Air Discharge
Air Discharge Louver
Air Intake
Air Intake
Thermal Insulation
Wrap the insulated pipe with the
finishing tape from bottom to top
M5CMY 28ER
Indoor Unit
Outdoor Unit
Thermal Insulation
Wrap the Insulated pipe with the
finishing tape from bottom to top
Air Discharge Louver
Air Intake Grille
Air Intake
Air Intake
Top Panel
Bottom Panel
Air Discharge
To Next Page
