M5LCY-II_(i) Engineering & Physical Data
23
Engineering & Physical Data
Engineering Data -M5CKY-ER
MODEL
INDOOR UNIT
M5CKY28ER M5CKY40ER M5CKY50ER
OUTDOOR UNIT
M5LCY28CR M5LCY40FR M5LCY50FR
NOMINAL COOLING CAPACITY
Btu/h
24200 35900 44400
W
7100 1052 1301
NOMINAL HEATING CAPACITY
Btu/h
28300 40600 48100
W
8300 11.90 1410
NOMINAL TOTAL INPUT POWER (COOLING)
W
2212 2740 3900
NOMINAL TOTAL INPUT POWER (HEATING)
W
2156 3030 3630
NOMINAL RUNNING CURRENT (COOLING) W
9.77 12.40 17.70
NOMINAL RUNNING CURRENT (HEATING)
A
9.53 13.70 16.40
EER
A
3.21 3.84 3.34
COP
W/W
3.85 3.93 3.88
REFRIGERANT CONTROL (EXPANSION DEVICE)
OUTDOOR EXV
REFRIGERANT CHARGE kg
1.80 3.95 3.95
POWER SOURCE V/Ph/Hz
220-240/1/50
REFRIGERANT TYPE
R410A
INDOOR UNIT
CONTROL
AIR DISCHARGE
AUTOMATIC LOUVER (UP & DOWN)
OPERATION
WIRELESS OR WIRED MICRO-COMPUTER REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM
410 / 860 490 / 1030 780 / 1200
MEDIUM l/s / CFM
342 / 725 406 / 860 486 / 1030
LOW l/s / CFM
293 / 620 349 / 740 439 / 930
QUIET l/s / CFM
250 / 530 293 / 620 368 / 780
SOUND PRESSURE LEVEL (H/M/L/SL)
dBA
41 / 38 / 35 / 32 44 / 41 / 38 / 35 47 / 44 / 43 / 39
UNIT DIMENSION HEIGHT X WIDTH X DEPTH
mm
265 X 820 X 820 300 X 820 X 820
WITH PANEL HEIGHT X WIDTH X DEPTH
mm
340 X 990 X 990 375 X 990 X 990
PACKING DIMENSION HEIGHT X WIDTH X DEPTH
mm
306 X 916 X 916 335 X 916 X 916
PANEL HEIGHT X WIDTH X DEPTH
mm
121 X 1016 X 1000
UNIT WEIGHT (UNIT + PANEL) kg
31 + 4 39 + 4 41 + 4
CONDENSATE DRAIN SIZE mm
19.1 19.1 19.1
FAN
TYPE
TURBO
DRIVE
DIRECT
FAN MOTOR
TYPE
INDUCTION
INDEX OF PROTECTION (IP)
IP20
INSULATION GRADE
CLASS B
RATED INPUT POWER W
152 176 221
RATED RUNNING CURRENT A
0.67 0.79 0.97
MOTOR OUTPUT W
50 60 100
POLES
4
COIL
TUBE
MATERIAL
INNER GROOVE COPPER
DIAMETER mm
7.00 7.00 7.00
FIN
MATERIAL
ALUMINIUM (SLIT FIN)
FACE AREA m
2
0.37 0.48 0.45
ROW
333
AIR QUALITY FILTER
TYPE
WASHABLE SARANET FILTER
QUANTITY pc
111
CASING COLOUR
WITHOUT PAINT
OUTDOOR UNIT
AIR FLOW l/s / CFM
1786 / 3034 3340 / 5675 3570 / 6065
SOUND PRESSURE LEVEL dBA
50 50 51
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm
753 x 940 x 392 1374 x 900 x 320
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm
793 x 990 x 415 1529 x 1030 x 421
UNIT WEIGHT kg
51
100
PIPE
CONNECTION
TYPE
FLARE VALVE
SIZE
LIQUID mm
9.52
GAS mm
15.87
FAN
TYPE
PROPELLER
DRIVE
DIRECT
FAN MOTOR
TYPE
BRUSHLESS DC MOTOR
INDEX OF PROTECTION (IP)
43
INSULATION GRADE
CLASS E
RATED INPUT POWER W
79 196 223
RATED RUNNING CURRENT A
0.91 1.26 1.43
MOTOR OUTPUT W
61 70 70
POLES
8
COMPRESSOR
TYPE
HERMETIC SWING SCROLL
OIL TYPE
DAPHNE FVC50K DAPHNE FVC68D
OIL AMOUNT cm
3
750 1000
RATED INPUT POWER (COOLING) W
NA 893
RATED INPUT POWER (HEATING) W
NA 853
RATED RUNNING CURRENT (COOLING) A
NA 4.19
RATED RUNNING CURRENT (HEATING) A
NA 4.63
COIL
TUBE
MATERIAL
COPPER
DIAMETER mm
7
FIN
MATERIAL
ALUMINIUM
FACE AREA m
2
0.37 1.14
ROW
32
CASING COLOUR
LIGHT GREY
DRAWING NUMBER
000452103N2828 000452103P4040 000452103P5050
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 8°C DB / 6°C WB
All SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
