McQuay M5CKY28ER User Manual

Engineering & Physical Data M5LCY-II_(i)
24
Engineering Data - M5CMY-ER
MODEL
INDOOR UNIT
M5CMY28ER M5CMY40ER M5CMY50ER M5CMY62CR
OUTDOOR UNIT
M5LCY28CR M5LCY40FR M5LCY50FR M5LCY60FR
NOMINAL COOLING CAPACITY
Btu/h
23200 34100 43000 47800
W
6800 10000 12600 14010
NOMINAL HEATING CAPACITY
Btu/h
26300 38900 52900 54300
W
7700 11400 15500 15910
NOMINAL TOTAL INPUT POWER (COOLING)
W
2420
3280 3600 4880
NOMINAL TOTAL INPUT POWER (HEATING)
W
2558
2920 4370 4530
NOMINAL RUNNING CURRENT (COOLING)
A
10.60
14.90 16.30 22.10
NOMINAL RUNNING CURRENT (HEATING)
A
11.20
13.20 19.60 20.40
EER
W/W
2.81
3.05 3.50 2.87
COP
W/W
3.01
3.90 3.55 3.51
REFRIGERANT CONTROL (EXPANSION DEVICE)
OUTDOOR EXV
REFRIGERANT CHARGE kg
1.80 3.95
POWER SOURCE V/Ph/Hz
220~240 /1/ 50
REFRIGERANT TYPE
R410A
INDOOR UNIT
CONTROL
AIR DISCHARGE
AUTOMATIC LOUVER (UP & DOWN)
OPERATION
WIRELESS OR WIRED MICROCOMPUTER REMOTE CONTROL
AIR FLOW
HIGH l/s / CFM
293 / 620 520 / 1100 570 / 1215 732 / 1550
MEDIUM l/s / CFM
269 / 570 464 / 983 511 / 1082 651 / 1320
LOW l/s / CFM
245 / 520 414 / 877 453 / 959 472 / 1000
SOUND PRESSURE LEVEL (H/M/L)
dBA
56 / 51 / 44 52 / 47 / 46 52 / 50 / 49 56 / 53 / 46
UNIT DIMENSION HEIGHT X WIDTH X DEPTH
mm
218 X 1080 X 630 260 X 1538 X 634 260 X 1786 X 634 285 X 1930 X 608
PACKING DIMENSION HEIGHT X WIDTH X DEPTH
mm
297 X 1197 X 740 330 X 1645 X 724 330 X 1892 X 724 351 X 2016 X 788
UNIT WEIGHT kg
27 45 65 70
CONDENSATE DRAIN SIZE mm
19.1
FAN
TYPE
SIROCCO
DRIVE
DIRECT
FAN MOTOR
TYPE
INDUCTION
INDEX OF PROTECTION (IP)
IP20 N/A
INSULATION GRADE
CLASS B CLASS E
RATED INPUT POWER W
117 190 240 297
RATED RUNNING CURRENT A
0.52 0.90 1.10 1.30
MOTOR OUTPUT W
70 118 149 80
POLES
4
COIL
TUBE
MATERIAL
INNER GROOVE COPPER PLAIN COPPER
DIAMETER mm
7.00 9.52
FIN
MATERIAL
ALUMINIUM
(SLIT FIN)
HYDROPHILIC
(RAISE LANCE)
HYDROPHILIC
(RAISE LANCE)
HYDROPHILIC
(SLIT FIN)
FACE AREA m
2
0.27 0.32 0.38 0.42
ROW
34
AIR QUALITY FILTER
TYPE
WASHABLE SARANET FILTER
QUANTITY pc
2 3 2+2 2+3
CASING COLOUR
LIGHT GREY
OUTDOOR UNIT
AIR FLOW l/s / CFM
1786 / 3034 3340 / 5675 3570 / 6065 3470 / 5896
SOUND PRESSURE LEVEL dBA
50 50 51 51
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm
753 x 940 x 392 1374 x 900 x 320
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm
793 x 990 x 415 1529 x 1030 x 421
UNIT WEIGHT kg
51
100
PIPE
CONNECTION
TYPE
FLARE VALVE
SIZE
LIQUID mm
9.52
GAS mm
15.87
FAN
TYPE
PROPELLER
DRIVE
DIRECT
FAN MOTOR
TYPE
BRUSHLESS DC MOTOR
INDEX OF PROTECTION (IP)
43
INSULATION GRADE
CLASS E
RATED INPUT POWER W
79 196 223 212
RATED RUNNING CURRENT A
0.91 1.26 1.43 1.36
MOTOR OUTPUT W
61 70 70 70
POLES
8
COMPRESSOR
TYPE
HERMETIC SWING SCROLL
OIL TYPE
DAPHNE FVC50K DAPHNE FVC68D
OIL AMOUNT cm
3
750 1000
RATED INPUT POWER (COOLING) W
NA 893 893 893
RATED INPUT POWER (HEATING) W
NA 853 853 853
RATED RUNNING CURRENT (COOLING) A
NA 4.19 4.19 4.19
RATED RUNNING CURRENT (HEATING) A
NA 4.63 4.63 4.63
COIL
TUBE
MATERIAL
COPPER
DIAMETER mm
7
FIN
MATERIAL
ALUMINIUM
FACE AREA m
2
0.37 1.14
ROW
32
CASING COLOUR
LIGHT GREY
DRAWING NUMBER
000452103M2828 000452103R4040 000452103R5050 000452103CY6260
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 8°C DB / 6°C WB
All SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
