McQuay M5CKY28ER User Manual

M5LCY-II_(i) Engineering & Physical Data
25
Engineering Data - M5CCY-CR
MODEL
INDOOR UNIT
M5CCY28CR M5CCY38CR M5CCY50CR M5CCY60CR
OUTDOOR UNIT
M5LCY28CR M5LCY40FR M5LCY50FR M5LCY60FR
NOMINAL COOLING CAPACITY
Btu/h
24200 34800 45400 47800
W
7100 10200 13310 14010
NOMINAL HEATING CAPACITY
Btu/h
27600 38200 53600 56600
W
8100 11200 15710 16590
NOMINAL TOTAL INPUT POWER (COOLING)
W
2212 3220 3960 4600
NOMINAL TOTAL INPUT POWER (HEATING)
W
2282 2920 4410 4600
NOMINAL RUNNING CURRENT (COOLING)
A
9.76 14.40 17.90 20.50
NOMINAL RUNNING CURRENT (HEATING)
A
10.10 12.90 19.90 20.50
EER
W/W
3.21 3.17 3.65 3.31
COP
W/W
3.70 3.83 3.87 3.96
REFRIGERANT CONTROL (EXPANSION DEVICE)
OUTDOOR EXV
REFRIGERANT CHARGE kg
1.80 3.95
POWER SOURCE V/Ph/Hz
220~240 /1/ 50
REFRIGERANT TYPE
R410A
INDOOR UNIT
CONTROL
AIR DISCHARGE
DUCTED
OPERATION
WIRED MICROCOMPUTER REMOTE CONTROL
AIR FLOW
SUPER HIGH l/s / CFM
401 / 850 604 / 1280 675 / 1430 812 / 1720
HIGH l/s / CFM
330 / 700 547 / 1160 623 / 1320 731 / 1550
MEDIUM l/s / CFM
278 / 590 496 / 1050 580 / 1230 632 / 1340
LOW l/s / CFM
226 / 480 434 / 920 533 / 1130 552 / 1170
EXTERNAL STATIC PRESSURE (SH/H/M/L)
Pa
78 / 53 / 38 / 25 118 / 96 / 78 / 61 147 / 126 / 109 / 92 147 / 120 / 90 / 69
SOUND PRESSURE LEVEL (SH/H/M/L)
dBA
44 / 41 / 38 / 34 55 / 51 / 48 / 45 53 / 52 / 50 / 47 55 / 53 / 50 / 47
UNIT DIMENSION HEIGHT X WIDTH X DEPTH
mm
285 X 1007 X 600 305 X 1302 X 638 378 X 1299 X 541 378 X 1499 X 541
PACKING DIMENSION HEIGHT X WIDTH X DEPTH
mm
343 X 1138 X 690 355 X 1461 X 727 415 X 1497 X 631 415 X 1701 X 631
UNIT WEIGHT kg
35 47 50 56
CONDENSATE DRAIN SIZE mm
19.1
FAN
TYPE
SIROCCO
DRIVE
DIRECT
FAN MOTOR
TYPE
1-Phase Fixed Speed
INDEX OF PROTECTION (IP)
IP21
INSULATION GRADE
CLASS B CLASS E
RATED INPUT POWER W
300 503 515 659
RATED RUNNING CURRENT A
1.30 0.93 1.07 1.01
MOTOR OUTPUT W
320 470 480 600
POLES
4
COIL
TUBE
MATERIAL
INNER GROOVE COPPER
DIAMETER mm
7.00
FIN
MATERIAL
ALUMINIUM (SLIT FIN)
FACE AREA m
2
0.24 0.35 0.41 0.48
ROW
3
AIR QUALITY FILTER
TYPE
WASHABLE SARANET FILTER
QUANTITY pc
2
CASING COLOUR
WITHOUT PAINT
OUTDOOR UNIT
AIR FLOW l/s / CFM
1786 / 3034 3340 / 5675 3570 / 6065 3470 / 5896
SOUND PRESSURE LEVEL dBA
50 50 51 51
UNIT DIMENSION HEIGHT X WIDTH X DEPTH mm
753 x 940 x 392 1374 x 900 x 320
PACKING DIMENSION HEIGHT X WIDTH X DEPTH mm
793 x 990 x 415 1529 x 1030 x 421
UNIT WEIGHT kg
51
100
PIPE
CONNECTION
TYPE
FLARE VALVE
SIZE
LIQUID mm
9.52
GAS mm
15.87
FAN
TYPE
PROPELLER
DRIVE
DIRECT
FAN MOTOR
TYPE
BRUSHLESS DC MOTOR
INDEX OF PROTECTION (IP)
43
INSULATION GRADE
CLASS E
RATED INPUT POWER W
79 196 223 212
RATED RUNNING CURRENT A
0.91 1.26 1.43 1.36
MOTOR OUTPUT W
61 70 70 70
POLES
8
COMPRESSOR
TYPE
HERMETIC SWING SCROLL
OIL TYPE
DAPHNE FVC50K DAPHNE FVC68D
OIL AMOUNT cm
3
750 1000
RATED INPUT POWER (COOLING) W
NA 893 893 893
RATED INPUT POWER (HEATING) W
NA 853 853 853
RATED RUNNING CURRENT (COOLING) A
NA 4.19 4.19 4.19
RATED RUNNING CURRENT (HEATING) A
NA 4.63 4.63 4.63
COIL
TUBE
MATERIAL
COPPER
DIAMETER mm
7
FIN
MATERIAL
ALUMINIUM
FACE AREA m
2
0.37 1.14
ROW
32
CASING COLOUR
LIGHT GREY
DRAWING NUMBER
000452103K2828 000452103Q3840 000452103Q5050 000452103Q6060
ALL UNITS ARE BEING TESTED AND COMPLY TO ISO 5151 (NON-DUCTED UNIT) OR ISO 13253 (DUCTED UNIT).
COOLING HEATING
INDOOR: 27°C DB / 19°C WB INDOOR: 20°C DB
OUTDOOR: 35°C DB / 24°C WB OUTDOOR: 8°C DB / 6°C WB
All SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
