M5LCY-II_(i) Sound Data
15
Model Speed
1/1 Octave A-Weighted Sound Pressure (dBA), ref 20μPa
Overall
(dBA)
Noise
Criteria
125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz
M5CMY
28ER
High 47 50 53 50 50 43 39 56 51
Med 44 46 49 46 45 38 33 51 46
Low 38 40 43 38 37 28 22 44 38
M5CMY
40ER
High 44 49 46 48 47 40 33 62 48
Med 42 47 44 45 43 33 26 47 44
Low 39 44 41 42 39 31 23 46 41
M5CMY
50ER
High 47 50 49 47 45 41 30 52 46
Med 45 48 47 46 43 38 28 50 45
Low 44 47 46 44 41 37 28 49 43
M5CMY
62CR
High 34 45 49 52 49 44 37 56 51
Med 32 43 46 49 46 41 33 53 48
Low 26 36 40 42 38 32 24 46 41
Part Number: 00153103M2828, 00153103R4040, 00153103R5050, 00153103CY6260
Model Measuring Location
M5CMY 28/40/50ER
1m
0.8m
Mircophone
Standard: JIS C 9612
M5CMY 62R
1m
1m
Mircophone
Standard: JIS B 8615
