Page iv
May 2005 1532ES / 1932ES Operatorās Manual
Machine Specifications
1532ES 1932ES
Working Height 21 ft 6.57 m 25 ft 7.79 m
Platform Height 15 ft 4.57 m 19 ft 5.79 m
Stowed Height: 75 in 1.90 m 79 in 2 m
Folded Down Rails NA NA NA NA
Maximum Number of Occupants 2
Lift Capacity (Evenly Distributed): 600 lbs 272.2 kg 500 lbs 226.8 kg
Roll-out Deck Capacity 250 Ibs 113.4 kg 250 lbs 113.4 kg
Platform Dimensions:
With Roll-Out Deck Retracted 31.5 x 66 in 0.96 x 1.68 m
Guard Rail Height 40.5 in 1.03 m
Toe Board Height 7 5/8 in 0.19 m
Roll-out Deck Length 36 in 0.91 m
Overall Length 74 in 1.88 m
Overall Width 31.5 in 0.96 m
Wheel Base 50 in 1.27 m
Wheel Track 27.37 in 0.70 m
Turning Radius:
Inside 2 in 0.05 m
Outside 67 in 1.7 m
Ground Clearance 3 in 0.76 m
Machine Weight (Unloaded) (Approx.) 2,725 lbs 1236 kg 3060 lbs 1388 kg
Drive System (Proportional):
Drive Speed (Platform Elevated) 0 - 0.5 mph 0 - 0.8 km/h
Drive Speed (Platform Lowered) 0 - 2.5 mph 0 - 4.02 km/h
Lift/Lower Speed (Approx.) 17 sec / 20 sec
Gradeability 25% / 14 degrees
Ground Pressure/Wheel (Maximum) 105 psi 7.4 bar 113 psi 7.9 bar
Wind Speed (Maximum) 0 mph 0 km/h
Tire Size-Standard (Solid, non-marking rubber) 14 in dia. x 4.5 in 35.56 cm x 11.43 cm
Tire Pressure (Not Applicable For Foam Tires) N/A
Wheel Lug Nut Torque 75 - 85 ft lbs 102 - 115 Nm
Hydraulic Pressure:
Main System 2750 psi 190 bar 2750 psi 190 bar
Lift System 1900 psi 131 bar 2600 psi 180 bar
Steer 850 psi 62 bar 850 psi 62 bar
Hydraulic Fluid Capacity 3 gal 11.36 liters
Fuel Capacity N/A
Power System ā Voltage 24 Volts DC
Battery Charger
Input 120 Volt AC, 60 Hz, 5.6 Amp
Output 24 Volt DC, 25 Amps Tapering,
Timed Shutoff
Batteries Four 6 Volt deep-cycle;
220 Amp hours @ 20 hour rating
Electric Motor 2.0 h.p. (1.49 kW): 3000 r.p.m.
Meets Requirements of ANSI A92.6-1999 Section 4
