Mec 4046SE - Machine Specifications

Page 4 SE
AC
Slab Series - Operator’s Manual
November 2022
Specications - 1930SE, 2632SE & 3346SE
1930SE 2632SE 3346SE
Working Height*
Indoor 25 ft 7.8 m 32.2 ft 10 m 38.8 ft 12 m
Outdoor 25 ft 7.8 m 26 ft 8 m 32 ft 10 m
Platform Height
Indoor 19 ft 5.8 m 26.2 ft 8 m 32.8 ft 10 m
Outdoor 19 ft 5.8 m 20 ft 6.1 m 26 ft 8 m
Maximum Drive Height 19 ft 5.8 m 26.2 ft 8 m 32.8 ft 10 m
Stowed Height
Top Guardrail 79.75 in 2.02 m 91 in 2.3 m 96.5 in 2.5 m
Rails Folded N/A 78 in 5 m 75 in 1.9 m
Platform Floor 40.75 in 1.04 m 48 in 1.22 m 53 in 1.35 m
Guardrail Height 39 in 1 m 43.5 in 1.11 m 43.5 in 1.11 m
Toeboard Height 6 in 15 cm 6 in 15 cm 6 in 15 cm
Machine Weight** (Unloaded) 3,440 lb 1,560 kg 4,870 lb 2,210 kg 5,670 lb 2,570 kg
Maximum Lift Capacity 550 lb 250 kg 550 lb 250 kg 800 lb 363 kg
Sheet Material Rack Capacity† 110 lb† 50 kg† 110 lb† 50 kg† 250 lb† 113 kg†
Deck Extension Capacity 1 Person / 250 lb (113 kg) 1 Person / 250 lb (113 kg) 1 Person / 250 lb (113 kg)
Maximum Occupants
Indoor 2 Persons 2 Persons 2 Persons
Outdoor 1 Person 1 Person 1 Person
Manual Force
Indoor 90 lbs 400 N 90 lbs 400 N 90 lbs 400 N
Outdoor 45 lbs 200 N 45 lbs 200 N 45 lbs 200 N
Length-Stowed (Overall) 74 in 1.86 m 97 in 2.46 m 97 in 2.46 m
Length-Stowed (Ladder Removed) 66 in 1.67 m
89.5 in 2.27 m 89.5 in 2.27 m
Platform Length (Extended) 100 in 2.54 m 124.5 in 3.16 m 124.5 in 3.16 m
Platform Length (Retracted) 65 in 1.65 m 89.5 in 2.27 m 89.5 in 2.27 m
Width (Overall) 30 in 76 cm 32 in 81 cm 47 in 1.19 m
Platform Width (Outside) 29 in 74 cm 32 in 81 cm 44 in 1.12 m
Wheel Base 54 in 1.36 m 74 in 1.87 m 74 in 1.87 m
Turning Radius - Inside 0 in 0 cm 0 in 0 cm 0 in 0 cm
Ground Clearance - Stowed 3.25 in 8.3 cm 4 in 10 cm 4 in 10 cm
Ground Clearance - Elevated 0.625 in 1.6 cm 0.7 in 2 cm 0.7 in 2 cm
Drive Speed
(Proportional)
Stowed 0-2.8 mph 0-4.5 km/h 0-2.5 mph 0-4.0 km/h 0-2.5 mph 0-4.0 km/h
Raised or Extended 0-0.5 mph 0-0.8 km/h 0-0.5 mph 0-0.8 km/h 0-0.5 mph 0-0.8 km/h
Gradability 25%/14° 25%/14° 25%/14°
Maximum Side Slope - Stowed 5° 5° 5°
Tilt Sensor Settings 2° side-to-side, 3° fore-and-aft 2° side-to-side, 3° fore-and-aft 2° side-to-side, 3° fore-and-aft
Ground Pressure/Wheel 130 psi 9.14 kg/cm
2
154 psi 10.8 kg/cm
2
160 psi 11.2 kg/cm
2
Maximum Wheel Load 1,180 lb 535 kg 1,600 lb 725 kg 1,900 lb 860 kg
Occupied Floor Pressure 263 psf 1,284 kg/m
2
268 psf 1,308 kg/m
2
224 psf 1,091 kg/m
2
Maximum Operating Wind Speed 28 mph / 12.5 m/sec (45 km/h) 28 mph / 12.5 m/sec (45 km/h) 28 mph / 12.5 m/sec (45 km/h)
Tire Size 12 × 4 inch / 305 × 100 mm 15 × 5 inch / 381 × 127 mm 15 × 5 inch / 381 × 127 mm
Wheel Bolt Torque 19 ft-lb / 25.5 Nm 43 ft-lb / 58.3 Nm 43 ft-lb / 58.3 Nm
Hydraulic Pressure 3,000 psi/ 207 bar 3,000 psi/ 207 bar 3,000 psi/ 207 bar
Power System Voltage 24 Volt DC / 210 Ah 24 Volt DC / 225 Ah
24 Volt DC / 240 Ah
Battery Charger
Input 110-230 V AC, 50-60 Hz 110-230 V AC, 50-60 Hz 110-230 V AC, 50-60 Hz
Output 24 Volt DC 24 Volt DC 24 Volt DC
Batteries Four 6-Volt deep cycle, 210 Ah Four 6-Volt deep cycle, 225 Ah Four 6-Volt deep cycle, 240 Ah
Chassis Inclination 1.5 Side 3.0 Inline 1.5 Side 3.0 Inline 1.5 Side 3.0 Inline
Meets requirements of ANSI A92.20-2020 and CSA B354.6-2019.
*Working Height adds 6 feet (2 m) to platform height.
**Weight may increase with certain options.
†Sheet material weight is part of the total platform capacity. This may limit capacity to one occupant.
Section 3 - Specications
Specications - 1930SE, 2632SE & 3346SE
