Mec 85-J - Page 19

Page 15 85
-
J - Operator’s Manual - 95803
January 2024Section 5 - Controls & Components
The upper band shows:
• Alarm indicator light
• Steering mode selection indicator light
• Parking brake active indicator light
• Di󰀨erential block active indicator light
• Front axle block active indicator light
• Movement speed selection indicator light: slow/fast
• Controls position indicator light: ground/basket
The central band shows:
• The engine rev counter to the left hand side
• The number of working hours in the center, the batteries voltage, the fuel level and the code of
the faulty of the engine
• The engine oil pressure indicator and the engine water temperature indicator on the right hand
side.
The bottom band shows the information shown on the pages that can be consulted:
• Engine data (RPM, drive torque percentage measured, coolant temperature, oil pressure, engine
consumption measured, instant and maximum fuel consumption, operating hours, quantity of
fuel used, required engine speed)
• Operational data (angular inclination of main boom, angular inclination of secondary boom,
inclination of the platform, inclination of the truck on the horizontal plane, load measured on
platform);
• Options settings (hydraulic preheat enable; Auto center steer; main boom retract conrmed;
range extender auto start sw; engine hood open sw; main boom angle<30°conrmed)
The setting interface could be entered by pressing the setting button and holding for one second. The
optional function can be turned on or o󰀨 without a password, after entering the setting interface. The
procedures are as follows:
1. Pressing “
ꜛ
/ +” or “
ꜜ
/ -” is used to choose the item
separately. The chosen item would be shown in yellow
background.
2. Pressing “On/O󰀨” and holding on is used to turn on or o󰀨
the corresponding function.
3. It returns back to main interface, when the button “Esc”
is pressed.
ART_5790
ILLUSTRATION No.
ꜛ
/ +
ꜜ
/ - On/Off Esc
Main Boom Angle <30° Confirmed OFF
Engine hood open SW OFF
Range extender auto starts SW OFF
Main Boom Retract Confirmed OFF
Auto Center Steer OFF
Hydraulic Preheat Enable
FUNCTION PARAMETER
OFF
