Mec 85-J - Maintenance Inspection Report

Page 42 85
-
J - Operator’s Manual - 95803
January 2024Section 8 - Maintenance
Maintenance Inspection Report
Booms (34J, 45J, 45AJ, 60J, 65J, 85J)
Fleet Equipment Number Date
Inspector Name Inspector Co.
Model Number Address
Serial Number
Hour Meter Signature
Machine Owner & address
Maintain all service records in accordance with ANSI A92.24-2019
* If an inspection receives an “N”, remove from service. Once repaired, place an “R” in the box.
* Refer to the proper service manual for specic information, settings and torque specications.
Key Y = Yes, Acceptable N = No, Remove from Service R = Repaired 0 = Not Applicable
QUARTERLY - Inspect only those marked “Q” ANNUAL - Inspect all items
Q/A Y/N/O R Q/A Y/N/O R
DECALS: BASE:
Legible - undamaged/readable A Fasteners tight Q
Capacity decal correct for model A Cover panels secure Q
PLATFORM: Welds, no signs of failure or damage A
No damage, all parts present Q Hydraulic hoses secure, no leaks A
Platform mounting fasteners secure Q Torque bolts on slew ring A
Entry gates secure, close properly Q Steering king pins, no excessive free play A
Manual box secure, Manuals inside Q COMPONENT AREA:
PPSS System operational (if equipped) Q Hydraulic; no leaks Q
ELEVATING ASSEMBLY: Hydraulic tank: correct level , breather clean Q
Lift Hyd Cylinders: no leaks, Q Hoses not damaged, Fittings tight Q
Booms do not bleed down with rated cap. Q Battery (ies) properly lled and cables clean Q
Hyd Hoses secure, no visible damage Q Hydraulic tank: Oil changed per listed intervals A
Beam structures: Straight, no cracks A Replace Hydraulic Filters A
Welds: secure, no cracks A Pressure relief valves, set correctly A
Pin Retainers in place, secure A OPERATIONAL INSPECTION:
Transport Lock: operational, lubed A All function speeds correct (see Specications) Q
Boom section shimming correct A Upper control box, operations correct, smooth Q
ELECTRICAL: Upper controls operate proportionally Q
GFCI operates correctly Q Emergency Down operates correctly Q
Comm cable: no damage, secure Q Limit switche(s) slow(s) drive when elevated Q
Wire harnesses: good cond, secure A Emergency stop switches, stop everything Q
Harness connections: no corrosion A Brakes operational A
WHEELS: **Check Platform Overload protection operation Q
Tires: No damage, Lug nuts torqued Q ENGINE:
King Pins lubed A Engine serviced per recommendations’ Q
Tires are leaning in leaning in or out A Oil and Coolant Levels correct Q
Drive motors tight, no leaks A Fuel lines secure, no leaks Q
All shields, guards in place, secure Q
Mounting secure Q
** If equipped with Platform Overload Protection
