January 2024Section 3 - Specications
Specications
Work Height
1
92 ft 28.1 m
Platform Height 85 ft 8 in 26.1 m
Maximum Drive Height 85 ft 8 in 26.1 m
Maximum
Outreach
Telescopic 70 ft 21.3 m
Articulated 60 ft 18.2 m
Turntable Swing 360° Continuously
Jib Range Of Motion 133°
Platform Rotation 180° (90° Each Side)
Machine Weight
2
(Unloaded) 37,480 lbs 17,000 kg
Lift Capacity
Unrestricted 600 lbs 272 kg
Restricted 900 lbs 408 kg
Maximum Occupants 2
Stowed Height 9 ft 5 in 2.92 m
Overall Length 37 ft 3 in 11.37 m
Overall Width 8 ft 4 in 2.59 m
Tailswing 5 ft 6 in 1.71 m
Wheel Base 9 ft 1 in 2.8 m
Platform
Details
Width 90 in 2.28 m
Depth 40 in 1 m
Entry 1 End Swing Gate, 2 Slide Bar Entries
Turning Radius, Inside 6 ft 1 in 1.87 m
Ground Clearance 1 ft 3 in 0.41 m
Lift Speed 55-70 seconds
Extend Speed 50-60 seconds
Jib Lift Speed 24-36 seconds
Drive Speed
(Proportional)
Stowed 3.7 mph 6 km/h
Raised/Extended 0.6 mph 1.1 km/h
Gradeability
Stowed, Downhill 45% (24.2°)
Stowed, Uphill 45% (24.2°)
Breakover Angle 40% (22°)
Axle Oscillation 14° (7° Each Side)
Maximum Wind Speed 28 mph 12.5 m/sec (45 km/h)
Engine 75hp Deutz TD 2.9 L4
Fuel Type Diesel
Fuel Capacity 35 gal 135 L
Hydraulic Fluid Capacity 52 gal 200 L
Meets requirements of ANSI A92.20-2020 and CSA B354.6-2019.
Allowable ambient temperature range: -20° F to 120° F (-29° C to 49°C).
Consult with MEC for operation outside of this range.
1
Working Height adds 6 feet (2 m) to platform height.
2
Weight may increase with certain options.
