Mec 85-J - Base Control Operations and Tests

Page 21 85
-
J - Operator’s Manual - 95803
January 2024Section 7 - Operating Instructions & Pre-Operation Function Tests
Base Controls Operation & Pre-Operation Functions Test
ART_5790
ILLUSTRATION No.
NOTICECAUTION
CAUTIONWARNING
ART_6091
ALWAYS check over, under and around the machine for personnel,
structures and obstructions before activating any control function and
continue to watch for hazards while operating the machine.
Press the Emergency Stop Switch at any time to stop all machine functions.
Turn switch clockwise to reset.
Depress the EMERGENCY STOP switch whenever the machine is not in
operation. Turn switch clockwise to reset.
ART_3353
Select BASE Operation
Be sure that the upper and lower EMERGENCY STOP Switches are reset.
Lower Control Box: Turn Key Switch to CHASSIS.
ART_6095
ILLUSTRATION No.
