Mec 85-J - Platform Control Panel

Page 27 85
-
J - Operator’s Manual - 95803
January 2024Section 7 - Operating Instructions & Pre-Operation Function Tests
Platform Control Panel
ART_5790
ILLUSTRATION No.
NOTICECAUTION
CAUTIONWARNING
ART_6091
ALWAYS check over, under and around the machine for personnel,
structures and obstructions before activating any control function and
continue to watch for hazards while operating the machine.
DO NOT hang anything over any control handle at any time.
Function Enable At Platform Controls
Note: If any Function Enable trigger or button is depressed for seven (7)
seconds without any function being activated, the Enable System times
out and deactivates. Release the trigger or button and reengage to
activate the Function Enable System.
The Drive function and most boom functions are enabled by squeezing the
trigger at the front of the appropriate control handle.
ART_4729
