5 Key Selector Switch
O󰀨 Select to stop operation from the lower control panel.
Platform Select to operate from the platform control panel.
Base Select to operate from the lower control panel.
6 Start/Stop Button Press the green button to start the engine or to turn the engine o󰀨.
7
Engine Speed Select
Switch
Use this switch to set the engine speed when functions are enabled. Setting this
switch to low idle speed allows the operator to move the machine slowly and
precisely.
Move this switch up for high idle speed and fast function speed.
Move this switch down for low idle speed and slow function speed.
8 Boom Mode Select Switch
Use this switch to set the boom mode:
Move this switch up to select Telescopic Mode which allows the telescopic boom
to be extended or retracted.
Move this switch down to select Articulated Mode which allow the riser boom to
lifted or lowered.
9 Turntable Rotate Switch
Move this switch left to rotate the turntable clockwise.
Move this switch right to rotate the turntable counterclockwise.
10 Riser Lift/Lower Switch
This function can only be activated when Articulated Mode has been selected.
Move this switch up to lift the riser boom.
Move this switch down to lower the riser boom.
11 Frame Level Switch Move this switch left or right to manually adjust the level position of the frame.
12 Overload Indicator Light
Light ON indicates too much weight on the platform.
An audible alarm will sound and all machine function will stop.
Remove weight from the platform to restore function and continue.
13 Emergency Stop Switch
Press the EMERGENCY STOP switch at any time to stop all machine functions.
Turn switch clockwise to reset.
14 Main Boom Lift/Lower
Move this switch up to lift the boom.
Move this switch down to lower the boom.
15 Diagnostics Display Panel
This panel contains the basic information for monitoring the working status of the
boom. See page 14.
16
Telescopic Boom Extend/
Retract Switch
This function can only be activated when Telescopic Mode has been selected.
Move this switch up to extend the boom.
Move this switch down to retract the boom.
17 Jib Lift/Lower Switch
Move this switch up to lift the jib.
Move this switch down to lower the jib.
18 Platform Rotate Switch
Move this switch left to rotate the platform clockwise.
Move this switch right to rotate the platform counterclockwise.
