10.0 The inserts
Sharp inserts.
The sharp edges of these inserts can be used to treat bone structures efciently and effectively.
Sharp inserts are used in osteotomy and osteoplasty when a ne and well-dened cut in the bone
structure concerned is required. There are also inserts with sharp edges for osteoplasty techniques
and for removing bone fragments.
Smoothing inserts.
The smoothing inserts have surfaces shaped in such a way that they can be used to work the bone
structures with precision and in a controlled manner. Smoothing inserts are used in osteotomy
when it is necessary to prepare difcult and delicate structures such as those for preparing a maxil-
lary sinus window or to complete preparation of the site of an implant.
Blunt inserts.
Blunt inserts are used for separating the soft tissues, for example for detaching Schneider’s
membrane or for lateralising nerves. In periodontology, these inserts are used to smooth the root
surfaces.
11.0 Symbols
12.0 Troubleshooting
If the device does not seem to be working properly, read the instructions again and then check the
following table.
PROBLEM POSSIBLE CAUSE SOLUTION
The device does not turn on
when the switch is positioned
on ON.
The connector on the end
of the power cable is not
plugged into the socket on the
rear of the device properly.
The power cable is faulty.
The fuses are unserviceable.
Check that the power cable is
rmly connected.
Check that the power outlet is
working properly.
Replace the power cable.
Replace the fuses (see point
“Replacement of fuses”).
The device is switched on but
will not work. No errors are
shown on the display.
The connector of the
footswitch is not properly
plugged into the socket.
The footswitch will not work.
Insert the footswitch
connector properly.
Contact the nearest
authorised MECTRON
Service Centre.
A faint whistle can be heard
coming from the Piezosurgery
handpiece during operation.
The insert is not correctly
tightened onto the scaler
handpiece.
Unscrew the insert and screw
it back into place correctly.
The device is switched on but
does not work. The message
ERR appears on the display.
The insert is not tted cor-
rectly into the handpiece.
The insert is worn, broken or
deformed.
The connector of the cord is
wet.
Unscrew the insert and screw
it back into place correctly.
Replace the insert.
Dry the connectors.
N.B.: Please read carefully the instructions for use.
�
Type “B” applied part.
This device and its accessories shouldn’t be
disposed or treated as solid urban waste.

Apparatus in accordance with EC Directive 93/42 EEC
Including EN 60601-1 and EN 60601-1-2.
Notied body: CERMET
The sterilisable materials must be autoclave sterilised
and can withstand a maximum temperature of 135° C.
