WARNING: Before connecting the cord to the device, make sure that the electrical
contacts are perfectly dry. If necessary, dry them with the air syringe.
04.2 - Initial Installation
To ensure perfect operation of the equipment, it is installed by technical personnel author-
ised by Mectron. The equipment will be installed in a suitable and handy place for it to be
used, and is enabled by entering an activating password.
The activating password is given to the technician responsible for installation and is not
indicated inside the package containing the device. The purpose of this is to ensure im-
mediate traceability of the device, as required according to current legislation.
The technician must:
- Install the device in a suitable place;
- Explain the main aspects of correct installation to the user;
- Fill in the installation form, including the purchaser’s data;
- Send the installation form to Mectron to ensure traceability and activation of the war-
ranty;
- Enter the activating password to enable the device.
04.3 - Connecting the Accessories
The accessories listed below have to be connected to the Piezosurgery device:
1 Insert the silicone tube into the peristaltic pump, proceeding as follows:
- Open the door (Fig.4 - Ref.A) as far as it will go (Fig.4 - Ref.B).
- Position the tube in the impeller (Fig.4 - Ref.C).
- Close the door completely (Fig.4 - Ref.E).
DANGER: Personal injury.
The footswitch of the Piezosurgery must not be activated when the door of the peristaltic
pump is open (Fig.4 - Ref.B). Moving parts could cause personal injury of the operator
2 Insert the rod for supporting the bag into the hole provided for it (Fig.5 - Ref.E).
3 Insert the handpiece support into the two holes provided for it (Fig.5 - Ref.C).
4 Connect the footswitch to the casing of the device by inserting the plug into the footswitch
socket (Fig.5 - Ref.H).
5 Plug the power cable into the connector on the casing of the device (Fig.5 - Ref.I) and
then into the power outlet.
6 Connect the Piezosurgery cord to the cord connector on the device (Fig.5 - Ref.D).
7 Insert the tube of the Piezosurgery into the pump fitting (Fig.5 - Ref.N). Insert the pump
fitting into the tube of the peristaltic pump (Fig.5 - Ref.M).
8 Connect end of the tube of the peristaltic pump (Fig.5 - Ref.L) to the flow-control sys-
tem.
9 Connect the flow-control system to the bag containing the appropriate liquid for the
treatment.
