MANUAL OF USE AND MAINTENANCE
05.0 - USE
05.1 - Controls
This section illustrates the parts of the front panel (Fig.6) of the Piezosurgery unit, ena-
bling the controls described in this manual to be located immediately.
Description of the controls
Ref. A - Graphic display.
Function The display shows the following information:
The type of power setting ROOT/BONE
The output power level set in the ROOT mode. ENDO/PERIO
The output power level set in the BONE mode. QUALITY 1/2/3
and SPECIAL
The delivery rate of the pump. PUMP: 5 Levels
The cleaning cycle for the liquid circuit. CLEAN
Ref. B - Pair of 2 keys: PUMP + and -. + -
Function These can be used to set the delivery rate of the peristaltic pump
Ref. C - Power-level key
Function This key is used to set the output power level required
Ref. D - Power-type key
Function This key is used to set the type of output power required: ROOT/BONE;
This key is used to set the CLEAN function by holding down the key for 5
seconds.
Other controls for operating the device are:
Ref. F (Fig.5) - The ON/OFF switch.
Function For supplying electricity to the device.
Ref. G (Fig.3) - The enabling footswitch.
Function For activating operation of the device.
05.2 - Switching the Device ON and OFF
Switching the device on
1 Power up the device by turning on the MAIN SWITCH (Fig.5 - Ref.F) situated on the
casing of the device, taking care not to press the footswitch.
2 The device will switch on.
Switching the device off
1 Power down the device by turning off the MAIN SWITCH (Fig.5 - Ref.F) situated on the
casing of the device.
2 The device will switch off.
