Genio 1200 Evaluation Kit User Guide
3 Interface and Connectors
3.1 Genio 1200 EVK I/O Connectors
Table 3-1 Main Board Connectors
Description Location Note
Battery Connector J1
DC Jack J2
DC-IN Power On Indicator LED 11 Red LED
System Power On Indicator LED 1 Red LED
Reset Indicator LED10 Yellow LED
Power On Button SW1
Reset Button SW2
Home Button SW3
Download Button SW4
Boot Switch SW5 Switch between eMMC and UFS
USB 3.2 J10 Dual USB Type-A 3.2 x 2
USB 3.2 Type-C J12 USB 3.2 Port / DP Display Port (MUX)
USB 2.0 J13 Micro USB
UART0 J34 Debug (Core Processor Log)
UART1 J52 Debug (SCP Log)
Micro SD Card Connector SD1
LCM0 Connector J4 7” MIPI DSI Panel (DSI 0)
LCM1 Connector J40 7” MIPI DSI Panel (DSI 1)
CTP0 Connector J39 7” Touch
CTP1 Connector J42 7” Touch
eDP Connector J8 17.3” eDP Panel
LVDS Connector J6 LVDS Panel
CAM0 Connector J30 MIPI CSI0 A/B Interface
CAM1 Connector J31 MIPI CSI0 C/D Interface
CAM2 Connector J32 MIPI CSI1 A/B Interface
Nano SIM Card Connector J14
Micro SIM Card Connector J15
M.2 3052 Key B Slot J18 RM500K-CN 5G Module
Wi-Fi Antenna (Aux) J21
Wi-Fi Antenna (main) J23
Wi-Fi Antenna (main spare) J25
M.2 2230 Key E Slot J26 AW-XB468NF(MT7921L) Wi-Fi Module
Ethernet J27
HDMI TX J28 HDMI Out
HDMI RX J29 HDMI In
Raspberry Pi Like I/O J33
To Next Page
