Genio 1200 Evaluation Kit User Guide
Raspberry Pi Like I/O Interface
Table 3-7 Pin Assignments of the Raspberry Pi Like I/O Pin Header
Pin #
Description Note Pin #
Description Note
1 3.3V 2 5V
3 SDA0 GPIO8 4 5V
5 SCL0 GPIO9 6 GND
7 GPIO-04 8 TXD1 GPIO102
9 GND 10 RXD1 GPIO103
11 GPIO-03 12 GPIO-05
13 GPIO-101 14 GND
15 GPIO-02 16 GPIO-01
17 3V3 18 GPIO-00
19 SPI0_MO GPIO142 20 GND
21 SPI0_MI GPIO143 22 GPIO-57
23 SPI0_CLK GPIO141 24 SPI0_CS GPIO140
25 GND 26 GPIO-100
27 SDA2 GPIO12 28 SCL2 GPIO13
29 GPIO-66 30 GND
31 GPIO-68 32 GPIO-65
33 PWM GPIO109 34 GND
35 SPI1_MI GPIO139 36 SPI1_CS
GPIO136
37 GPIO-67 38 SPI1_MO
GPIO138
39 GND 40 SPI1_CLK
GPIO137
Note:
1. VDD_5V power can provide 5V/2A maximum but share with USB Host VBUS 5V output
2. VGPIOEXT_3V3 power can deliver 3.3V/300mA
3. Black words are ground pins
4. Red words are power pins
5. Green words are special function pins
6. Blue words are GPIOs
7
. Pink words are pins, which multiplex with other function. Please check section 3.16 Pin Mux for Other Interfaces
