Genio 1200 EVK
Genio 1200 Evaluation Kit User Guide
Figure 2-2 Genio 1200 EVK Top View
RJ-45
Connector
CAN FD
Connector
Raspberry Pi Like
Connector
Earphone
Connector
Speaker
Connector
DC IN
Jack
Battery
Connector
Wi-Fi ANT1
Connector
Wi-Fi ANT2
Connector
Wi-Fi ANT3
Connector
Camera CAM2
Connector
Camera CAM1
Connector
Camera CAM0
Connector
USB 3.2
Connector
HDMI RX
Connector
Download Key
M.2 Connector for
MT7921 Wi-Fi Module
HDMI TX
Connector
UART 0 Debug
Connector
Micro USB
Connector
UART 1 Debug
Connector
USB Type-C
Connector
Power Key
Reset Key
Home Key
eDP Connector
eMMC / UFS
Switch
