Genio 1200 EVK
Genio 1200 Evaluation Kit User Guide
1.3 Feature Summary
 MediaTek CPU (MT8395IV/ZA)
 MediaTek PMIC (MT6365IAW/B)
 4GB LPDDR4X RAM x 2 (Micron MT53E1G32D2FW-046 IT:B)
 64GB eMMC x 1 (Western Digital SDINBDG4-64G-XI2)
 Φ2.0 DC Jack x 1 (for 12V DC Input)
 Micro SD Card Connector x 1
 Push Button x 4 (Power, Reset, Home and Download)
 LED x 3 (System Power, Reset, DC-IN Power)
 4-Lane MIPI DSI x 2
 4-Lane MIPI CSI x 3
 HDMI x 2 (IN x 1, OUT x 1)
 LVDS x 1
 eDP x 1
 10/100/1000M Ethernet x 1 (Realtek RTL8211FI-CG)
 Micro USB x 2 (device, UART)
• UART Port for Trace Log with USB to UART Bridge IC
 USB Type-A 3.2 Connector x 2
 USB Type-C Connector (USB 3.2/DP MUX)
 3.5mm Earphone Jack x 1 (with Microphone Input)
 3.5mm Line Out Audio Jack x 1
 Analog Microphone x 3 (Merry MMA102-006)
 Digital Microphone x 2 (Merry MMA102-007)
 UART Port x 1 (6 PIN/2.54mm Pin Header)
 M.2 Slot Key E x 1
• For AzureWave AW-XB468NF Wi-Fi 6 & BT 5.2 Module
 M.2 Slot Key B x 1
• For Quectel RM500K-CN 5G Sub-6 Module
 40-Pin 2.54mm Pin Header x 1 (for Raspberry Pi Like
I/O Interface)
 Micro SIM x 1
 Nano SIM x 1
 Operating Temperature: -40°C ~ 85°C
