Mediatrix 1104 - Calls Involving Another Access Device; Calls Involving an Access Device and a LAN Endpoint

Chapter 1 - Using the Mediatrix 1104 User’s Manual (SIP Version)
Mediatrix 1104
2
Calls Involving
Another
Access Device
The following example illustrates how to reach a phone or fax on
another Mediatrix 1104 access device.
X Phone/Fax -> Mediatrix 1104 A -> Mediatrix 1104 B -> Phone/Fax
A user makes a call with the phone/fax connected to a Mediatrix 1104,
which in turn contacts another Mediatrix 1104, then reaches the
corresponding phone/fax.
Calls Involving
an Access
Device and a
LAN Endpoint
The following examples illustrate how a phone/fax connected to a
Mediatrix 1104 access device can communicate with a LAN Endpoint
on the IP network.
X Phone/Fax -> Mediatrix 1104 -> LAN Endpoint
A user makes a call with the phone/fax connected to a Mediatrix 1104,
which reaches the corresponding LAN Endpoint on the IP network.
Telephone
y IP phone
y Soft Phone
Mediatrix 1104 Mediatrix 1104
Fax
Telephone
Fax
Server
LAN Endpoint
IP
Telephone
y IP phone
y Soft Phone
Mediatrix 1104 Mediatrix 1104
Fax
Telephone
Fax
Server
LAN Endpoint
IP
