SCOPE BUDDY USER/SERVICE MANUAL
16
Figure 3 Scope Buddy Line Hook-up
Note: The endoscope leak test must be performed prior to commencing the cleaning
process according to manufacturer’s guidelines.
Note: Detergent and rinse water cleaning solutions can be drawn from either a clean
container for a single-pass through Scope Buddy, or recirculated from the sink through Scope
Buddy. Scope Buddy can be used in either format depending on the facility’s endoscope
cleaning procedure.
Caution: Verify fluid exiting the open end of the endoscope or tubing is not facing a direction
that would allow fluid to be sprayed on personnel or electrical fixtures. The endoscope should
always be fully immersed under water.
Flushing an Endoscope with Detergent:
1. Plug the unit in and then turn it on by pressing the power switch located on the side of the unit. The
timer display will now illuminate. See Figure 3.
DSD Extension Line Fluid Intake Line
Sco
e Budd
Unit
