MEGADYNE MEGA POWER - Output Power Characteristics

26
Type and Rating of Fuses: 2 each F10.0/250V
Electrical properties
Nominal Operating Voltage: 100 – 240 VAC
Nominal Operating Frequency: 50-60 Hz
Output Power Variation
Output variation as a function of input variation <5%
Output Power Characteristics
Mode
Power
(Watts)
Output
Tolerance
Rated
Load
Ohms
Maximum
Open Circuit
Voltage
Vp-p
Operating
Frequency
kHz
Crest Factor
Nominal @
Rated Load
Monopolar CUT
ACE Cut 150 20% 200 1500 400 1.4
Pure Cut 300 20% 300 3000 400 1.4
Blend 200 20% 300 4000 400 3.0
Monopolar COAG
Spray 120 20% 500 7200 400 8.0
Standard 120 20% 500 5800 400 7.4
Coag with Cut 120 20% 500 4000 400 6.0
Bipolar
Standard/Micro 80 20% 100 760 400 1.4
Macro 80 20% 100 760 400 1.4
Low Frequency (50 - 60 Hz) Leakage Current
NC SFC
Earth Leakage Current general < 300 A < 1.0 mA
Enclosure < 100 A < 500 A
Patient Leakage Current < 10 A < 50 A
Patient Auxiliary Current d.c. < 10A < 50 A
Patient Auxiliary Current a.c. < 100A < 500 A
High Frequency (RF) Leakage Current
Monopolar Modes (all settings at the maximum)
Patient Return to Ground <150mA
Active to Ground <150mA
Bipolar Mode (Maximum setting)
Each Lead to Ground < 63mA
