MEGADYNE MEGA POWER - Parts List

55
Parts List
Description Part Number
Center Heatsink Assembly 6020089-01
Mother Board Assembly 6020088-01
High Voltage Connector Assembly 6020090-01
Right Side Heatsink Assembly 6020091-01
Left Side Heatsink Assembly 6020092-01
Front Panel Molded Nosecone w/o PCB 6020093-01
Front Panel Assembly with PCB 6020094-01
Controller PCB 6020095-01
Power conversion PCB 6020096-01
Foot Control PCB 6020097-01
Top cover Assemblyy 6020098-01
Fan (3 x 3 x 5) with Connector 6020099-01
Fan (2.4 x 2.4 x 5) with Connector 6020100-01
Harness, Foot Control to Main PCB 3750009-01
Harness, Controller to Front Panel 3750010-01
Harness, Power, Main to Switch 3750011-01
Harness, Power Switch to PFC 3750012-01
Harness, Power PFC to LV Supply 3750013-01
Harness, Low Voltage Supply to Main 3750014-01
Harness, Line Ground to Chassis 3750015-01
Fiber Optic Cable 3750019-01
Low Voltage Power Supply 4600012-01
AC Power Switch 4600038-01
3 Amp Motherboard Fuse 4600040-02
Line Filter Fuse 4600039-01
Cord, Power, 15' 4600034-01
Screw, Phillips, Pan Head, 4-40 X 1/4 5600006-01
Screw, Phillips, Pan Head, 4-40 X 3/8 5600006-02
Screw, Phillips, Pan Head, 4-40 X 2.0 5600006-03
Screw, Phillips, Flat Head 4-40 X 1/4 5600007-01
Screw, Phillips, Flat Head 6-32 X 3/8 5600007-04
Screw, Phillips, Flat Head 6-32 X 3/8 5600007-05
Screw, Phillips, Flat Head 6-32 X 5/8 5600007-10
Screw, Phillips Pan Head SEMS 6-32 X 3/8 5600008-02
Screw, Phillips Pan Head SEMS 6-32 X 5/8 5600008-03
Screw, Phillips Pan Head SEMS 6-32 X 3/8 5600008-05
Screw, Phillips Pan Head SEMS 4-40 X 5/16 5600008-06
Standoff, Hex .25 X 1.125 4600031-01
Standoff, Hex .25 X 2.25 4600028-01
Module, Power Entry, 10A 4600014-01
Knob, Volume control 4600037-01
