38
Bipolar Output Power Graphs
Bipolar - Output Power vs Load Resistance
0
10
20
30
40
50
60
70
80
90
0 500 1000 1500 2000 2500
Load Resistance (Ohms)
Power (W)
Bipolar - Power Output vs Power Max
0
10
20
30
40
50
60
70
80
90
0 10 20 30 40 50 60 70 80
Power HF Maximum (W)
Power HF Output (W)
Rl = 100 Ohms
