3.4 Auto Save — Auto and continuous
Auto save and logging results
Press save before running
i) Auto test - save all auto test results.
ii) Continuous test - log results every 5 seconds.
iii) If internal memory is full, delete some records to create space
- refer to Saving a test record section 3.3
100A
50A
10A
Ω
MAN
AUTO
MAN
AUTO
3.5 Auto test progress screen with auto save
3.6 Continuous test progress screen - Logging results
100A
50A
10A
Ω
100A
50A
10A
Ω
MAN
AUTO
MAN
AUTO
