Megger DLRO100E User Manual

www.megger.comDLRO100E, 100X & 100H – 100A
6
Instrument controls and indicators
1. Current terminals
– C1 - C2
2. C1 - C2 LED
indicates continuity
on the C terminals
3. P1 - P2 LED
indicates continuity
on the P terminals
4. Potential terminal
- P1 - P2
5. Measurement earth
terminal
6. DualGround™ terminal
100X and 100H only
7. Save button
100X and 100H only
8. Range rotary switch
9. TEST button with
associated warning lamp
10. Navigation / OK buttons
11. Test mode rotary switch
12. Backlight button
13. Display
14. LED indicating line
power / mains
15. Power socket
16. USB Device port
100X and 100H only
17. Cooling fans with
IP54 cover
17
90-264 V
500 VA
47-63 Hz
N13117
DLRO100EB
Made in UK by Megger
15
16
MAN
AUTO
100A
50A
10A
Ω
DLRO100
TEST
OK
C1 - - C2
P1 - - P2
C1
C2
P1
P2
600 V
600 V
600 V
600 V
MAX
MAX
MAX
MAX
CAT IV
600 V
2
3
1
4
5
6
13
14
7
8
910
12
11
