Megger DLRO100E User Manual

www.megger.comDLRO100E, 100X & 100H – 100A
10
100A
50A
10A
Ω
1.2 Preset test
100/50/10A - Progress
1.1 Preset test
100/50/10A - Initial
Select current on rotary switch.
Press test button to start the test.
To configure date and time for saved results - refer to Instrument
set-up section 2.6
MAN
AUTO
MAN
AUTO
Active test screen.
1. Testing modes
Manual and auto test
TEST
1.3 User configured Manual and Auto test - Initial
Press test button to start a custom test.
To configure test setting for user configured test, date and time
for saved results - refer to Instrument set-up section 2.6
1.4 User configured Manual and Auto test - Progress
Active custom test screen.
100A
50A
10A
Ω
100A
50A
10A
Ω
MAN
AUTO
MAN
AUTO
MAN
AUTO
Continuous test
1.5 Preset test 100/50/10A - Initial 1.6 Preset test 100/50/10A - Progress
Press test button to start a continuous test.
To configure date and time for saved results - refer to Instrument
set-up section 2.6
Active continuous test screen.
TEST
100A
50A
10A
Ω
100A
50A
10A
Ω
MAN
AUTO
MAN
AUTO
MAN
AUTO
100A
50A
10A
Ω
MAN
AUTO
MAN
AUTO
