2 Technical Description
2.1 Technical Data
Technical data The following parameters are specified for the Easytest receiver:
Parameter Value
Output voltage (DC) 0 ... -20 kV
Source output current 15 mA
Display ranges
Leakage current measurement
0 ... 1 mA, 0 ... 50 mA
0 ... 1 mA, resolution 5 %
Output voltage AC test 0 ... -20 kVDC, 0 ... +20 kVDC
AC test frequency 0,1 Hz for C ≤ 0,5 µF
0,05 Hz for C > 0,5 µF ≤ 1,0 µF
0,02 Hz for C > 1,0 µF < 2,5 µF
0,01 Hz for C > 2,5 µF < 5,0 µF
Voltage wave shape Resembling a rectangle
Testable cable capacitance ≤ 5,0 µF
Sheath test and pinpointing output voltage 0 ... - 5 kVDC / 0 ... -10 kVDC
Output current
Sheath test
Sheath fault pinpointing
DC, Imax = 15 mA
1:3, Imax = 25 mA
Test duration
Range
Interval
0 ... 60 min
First 5 minutes: adjustment in 1-minute steps
Thereafter: adjustment in 5-minute steps
Safety circuit FOhm BE and PE monitoring
External voltage protection (output
separation) (optional)
max. 12 kVAC (optional)
Power supply
230 V ±10 %, 50 ... 60 Hz or
115 V ±10 %, 50 ... 60 Hz
Front panel fuse: 6.3 A MT
Front panel fuse: 10 A MT
Power consumption max. 750 VA
Operating temperature range -20 °C ... +50 °C
Operating humidity +30 °C, 93 % relative humidity
Storage temperature range -25 °C ... +60 °C
Protection class (DIN VDE 0140 T.1) I
Type of protection IP 40 according to EN 60529,
IP 54 with lid closed
Dimensions (W x H x D) 480 x 290 x 495 mm
Weight 17 kg
19 kg, including wiring harness
