3-12
Safety instructions for setting up
• Select a location which is sufficient for t
he weight and size of the system and
ensures that it stands securely.
• When setting up the Easytest system, make sure no other systems or components
are impaired in their function. If other systems and components have to be modified
in order to set up and operate the test systems, make sure these actions are
reversed when the work is finished. Always take the special requirements of these
systems and components into account and only carry out work on them after
consulting and obtaining approval from whoever is in charge of them.
• Install protective equipment (such as railings, chains or bars) to block access to
the hazard zone and prevent the risk of touching live parts.
3.1 Electrical connection of the Easytest System
Safety instructions on electrical connection
• Always follow the safety instructions in section 1.2 General Cautions and
Warnings - in particular the five safety rules - before connecting the test object.
• The Easytest
may only be connected to or disconnected from a test object when it
is switched off, and only when the test object is earthed and shorted.
• After releasing the test object, make sure that dangerous voltage cannot reach
unprotected places or technical equipment.
• The discharge switch installed in the device is merely an apparatus for safely
discharging capacitance, and not an earthing and shorting device as described
by VDE 0104.
• All voltage transformers have to be disconnected from the cable under test before
starting a test measurement.
