80 TM1700-SERIES ZP-BL16E BL1448GE
9 DATA ANALYSIS
9
Data analysis
9.1 Analysis window
(CABAana)
The test results are presented graphically and as
parameter values here. The results can be analyzed
in detail, and a report can be generated. In addi-
tion to the functions presented below, a number of
Windows® functions are available (moving and edit-
ing windows and columns and using scroll bars for
example).
The following functions are available in the instru-
ment/analysis program:
File menu
Open
Opens a new recording (set of readings). Double-click
to select; breakers, tests and recordings.
Close
Close the recording (set of readings) in the active
window.
Print
Open the printer dialogue box for printing the com-
puter screen.
