When using the external current measurement func-
tion:
1. Check that the CT is connected in the right cur-
rent direction.
2 Always replace the CT internal battery before a
test.
3 Set the correct current ratio in the external current
measurement menu.
Never use the TORKEL/TXL Extra Load in an explo-
sive environment. Never put the TORKEL/TXL Extra
Load where it can be reached by battery gas.
Improperly connected cables carrying high current
can cause fire. Make sure that the cables are not
twisted in such a way that could cause them to turn
and come loose from the connector.
Position TORKEL/TXL Extra Load where air flow is
unobstructed and where it does not come into con-
tact with any flammable or heat-sensitive material.
Keep a free distance of 1.5 m (5 ft) to the verti-
cal sides of TORKEL/TXL and 2.0 m (6.5 ft) above
TORKEL/TXL.
Do not place TORKEL a) near another TORKEL, a TXL
Extra Load or any other heat source or b) where the
cooling airflow can be blocked. TORKEL will over-
heat if there is insufficient cooling.
External current shunt may not be used above
300 V DC
Important!
Make sure that the clamp-on ammeter is properly
connected and that its battery lasts throughout
the entire test. If external current measurement
malfunctions, TORKEL might provide a higher load
current than intended.
Do not use liquid detergents or aero-sols when
cleaning TORKEL or TXL units. Use a damp cloth.
If TORKEL has been stored below freezing for an
extended period of time, you must allow 3 hours for
it to adapt to room temperature.
