Megmeet MV300 Series - Control Parameters and Status Parameters of Drive

237
Bit Features Value Meaning
BIT8~BIT6 Display unit
000 No unit
001
The unit is Hz
010 The unit is A
011 The unit is V
100 The unit is r/min
101 The unit is line speed (m/s)
110 The unit is percentage (%)
Others Reserved
BIT9 Reserved
BIT10
Restore to
leave-factory
value
1 Restore
0 Do not restore
BIT11 Quick menu
1 Enabled
0 Disabled
BIT12 Basic menu
1 Enabled
0 Disabled
BIT13
16-bit/32-bit
parameter
1 32-bit
0 16-bit
BIT15~BIT14 Reserved
7. Change multiple function code parameters and status parameters of the drive, and the parameter
values will be saved after power off.
The command code 0x43 is used to change multiple function code parameters or control parameters of the
drive, and store the values into the nonvolatile memory cell.
Its command format is the same as that of 0x10. The only difference is as follows: the parameter value
changed under the 0x10 command will not be saved upon power off, but the parameter value changed under
the 0x43 command will be saved upon power off.
6. Control parameters and status parameters of drive
The control parameters of the drive can realize the start, stop, running frequency setting and other functions of
the drive. Inquiring the status parameters of the drive can get the parameters like the running frequency,
output current and output torque of the drive, etc.
1. Control parameters
The control parameters of the drive are as shown in the following table:
