121
P01.23 is used to display the percentage of the analog output relative to the full range. For example, the
function of AO1 is set as “output frequency”. If the maximum frequency is 100Hz and actual running
frequency is 50Hz, P01.23 will displays 50%.
P01.25~P01.28 are used to display the percentage of the process closed loop reference, feedback, error
and output in Group P14 relative to the full range.
The estimated temperature of motor indicates the motor temperature estimated. Temperature display
range: 0~150
℃; precision: 5％.
ASR controller output.
Corresponding value of the torque reference command.
Indicating the input pulse frequency of terminal X6.
6.3 Basic parameters (Group P02)
P02: Basic parameters
The group of basic parameters are mainly used to the basic parameters that are necessary for the drive
operation, such as control mode, main/auxiliary frequency reference and calculation,
acceleration/deceleration time, etc. The set frequency of the MV300 drive can be combined by the main
set frequency and the auxiliary set frequency. P02.04~P02.06 are used to define the main set frequency
and P02.07~P02.09 are used to define the auxiliary frequency. The Fig. 6-5 shows the process of
adjusting the proportion of the main set frequency and the auxiliary set frequency to form the set
frequency.
Pulse frequency of terminal X6 0.0~100.00kHz (0.0)P01.42
Reserved 0P01.33~P01.41
Torque reference -300.0~300.0% (0.0%)P01.32
ASR Controller output -300.0~300.0% (0.0%)P01.31
Reserved 0P01.30
Estimated temperature of moto
0~200℃(0)P01.29
Process closed loop output -100.0~100.0%(0.0%)P01.28
Process closed loop erro
-100.0~100.0%(0.0%)
P01.27
Process closed loop feedbac
-100.0~100.0%(0.0%)
P01.26
Process closed loop reference
-100.0~100.0%(0.0%)
P01.25
Reserved
0
P01.24
